Genie telescopic S-booms have working heights of 14.20 meters to 40.15 meters and a horizontal reach of between 9.65 meters and 24.38 meters. Compared with different other aerial work platforms, telescoping booms have a a range of horizontal reach that is much greater. Genie telescopic booms are designed with consideration to being able to access confined places during construction and industrial jobs. They are also known for their ability to maneuver through a job site quickly and with great traction and drive speed. The platform hydraulically turns 160�° and can stay level through the whole range. Front-entry platforms come with 227 kilogram to 272 kilogram capacity for operators and tools and are available from 1.83 meters to 2.44 meters. Continuous, 360�° rotating turntables offer quick, easy positioning for operators.
The Z-135/70 model has a telescoping jib, called the Jib-Extend, which goes from 3.66 meters to 6.1 meters. This specific unit can also reach 110�° vertically to give the user the ability to reach jobs that were previously unreachable by conventional jibs. A secondary reverse-articulating boom on the Z-80/60 model gives the user 8.83 meters of up and over reach. This specific feature enables up and over reaching tasks to be completed with zero front arm swing.
Genie also offers the Fast Mast system that allows for valuable time to be saved when both secondary and primary booms need to be lifted or for lowering the platform without having to lower the secondary boom. The Fast Mast system allows both booms to be elevated fully at the same time. Both of these features of the Genie Fast Mast system reduces the time needed for users to ascend and descend, increasing effectiveness and productivity.
